Momentum

Momentum

$160.00 CAD
$160.00 CAD
Sale Sold out
Shipping calculated at checkout.
Pre-Soldered Connecters Add-On

Docs | Schematics | 3D Model | Firmware | Arduino Library (SPI) | Arduino Library (CAN)

A Uno-style footprint sensor integration board that bridges an SPI or CAN host to sensor telemetry. It combines a 9-DOF IMU, multi-constellation GNSS, and a barometric pressure sensor on a single board, allowing rapid integration of a full sensor suite into any project with an SPI or CAN bus host controller.

Key features:

  • 9-DOF Inertial Measurement Unit (IMU) via the BNO086.
  • Multi-constellation GNSS via the SAM-M10Q module.
  • 24-bit absolute barometric pressure via the BMP390.
  • SPI or Classic CAN host interface for sensor telemetry.
  • Firmware update with the onboard USB-C serial interface via the CP2102N.
  • Addressable RGB LED for status display.
  • Dual 5 V source via USB-C or supply pin, with automatic power switching.
  • Jumper selectable 5 V or 3.3 V logic level for the SPI host interface.

Note: Product may slightly differ from photos.

View full details

Details

Intended Use: Non-Consumer, Engineering Tool

This product is designed for non-consumer use. It is intended as an engineering tool for testing and research.

Technical Documentation

Technical documentation can be found on a product's respective github.io website, please see the product description.

GitHub ScalpelSpace Technical Documentation Page: docs.scalpelspace.com.
